1/2 5/8 5/16
RETEKOOL
Availability: | |
---|---|
Quantity: | |
1.Refrigerant moisture ingression and heat resistance, excellent whip test resistance and noise reduction
2.Aging resistance,Ozone resistance,Low permeability,Flexible
3.Special tube compound resistant to high compression for coupling integrity.
Temperature: -40℃ to +135℃
SIZE (inch) | IDxOD | MinB.Rad | W.P | B.P | W.G | length |
mm | (mm) | (PSI) | (PSI) | (KG/M) | (M/ROLL) | |
5/16" | 8.0x19.0 | 95 | 3.5MPa | 18MPa | 0.21 | 50 |
13/32" | 10.2x22.3 | 110 | 3.5MPa | 18MPa | 0.29 | 50 |
1/2" | 13.0x23.3 | 120 | 3.5MPa | 14MPa | 0.36 | 50 |
5/8" | 16.0x26.3 | 130 | 3.5MPa | 14MPa | 0.44 | 50 |
1.Refrigerant moisture ingression and heat resistance, excellent whip test resistance and noise reduction
2.Aging resistance,Ozone resistance,Low permeability,Flexible
3.Special tube compound resistant to high compression for coupling integrity.
Temperature: -40℃ to +135℃
SIZE (inch) | IDxOD | MinB.Rad | W.P | B.P | W.G | length |
mm | (mm) | (PSI) | (PSI) | (KG/M) | (M/ROLL) | |
5/16" | 8.0x19.0 | 95 | 3.5MPa | 18MPa | 0.21 | 50 |
13/32" | 10.2x22.3 | 110 | 3.5MPa | 18MPa | 0.29 | 50 |
1/2" | 13.0x23.3 | 120 | 3.5MPa | 14MPa | 0.36 | 50 |
5/8" | 16.0x26.3 | 130 | 3.5MPa | 14MPa | 0.44 | 50 |
