RETEKOOL
| Availability: | |
|---|---|
| Quantity: | |
Jinan Retek Industries Inc. is a main refrigeation parts supplier in China. Our main products are condensers, evaporators, compressors, filter driers, access valves, accumulators etc. refrigerator parts, auto ac parts, etc. Up to now,We now export our products to more than 70 countries and regions. Our customers are from all over the world.
Features:
To be intended for low pressure oil control system and suitable for use with HFC and HCFC refrigerants(R134a,R404A,R507,R407A,
To be designed for use with scroll and reciprocating type compressor.not recommended for screw or rotary vane compressors
How to work The refrigeration gas containing oil in aerosol form from the compressor enters the oil separators. the oil contained in the refrigerant gas is intercepted when it passes through he inlet metal screen and middle baffle, and the velocity of the gas is reduced.the fine oil particle collide with one another and form heavier oil particles that impinge on the inner wall of the oil separators shell.the gas then passes through the outlet sreen where final separation take place. the separated oil drips to the Bottom of the oil separator where a floatball operated needle valve returns the oil back to the crankcase or oil reservoir.
Technical Parameters
·Medium Temperature:-40~+120"C
·Max.working pressure:31Bar
Burst pressure:190 Bar
·Oil storage volume: 55833-559011/5301-5305 600ml
Jinan Retek Industries Inc. is a main refrigeation parts supplier in China. Our main products are condensers, evaporators, compressors, filter driers, access valves, accumulators etc. refrigerator parts, auto ac parts, etc. Up to now,We now export our products to more than 70 countries and regions. Our customers are from all over the world.
Features:
To be intended for low pressure oil control system and suitable for use with HFC and HCFC refrigerants(R134a,R404A,R507,R407A,
To be designed for use with scroll and reciprocating type compressor.not recommended for screw or rotary vane compressors
How to work The refrigeration gas containing oil in aerosol form from the compressor enters the oil separators. the oil contained in the refrigerant gas is intercepted when it passes through he inlet metal screen and middle baffle, and the velocity of the gas is reduced.the fine oil particle collide with one another and form heavier oil particles that impinge on the inner wall of the oil separators shell.the gas then passes through the outlet sreen where final separation take place. the separated oil drips to the Bottom of the oil separator where a floatball operated needle valve returns the oil back to the crankcase or oil reservoir.
Technical Parameters
·Medium Temperature:-40~+120"C
·Max.working pressure:31Bar
Burst pressure:190 Bar
·Oil storage volume: 55833-559011/5301-5305 600ml
